Aug 01, 2017 It supports J2534 protocol, and it will support other protocol for free later. Screen record on mac sierra. Vlc player mac herunterladen. In addition, the FVCI J2534 VCI supports multiply communication manner of DOIP protocol, and it can set up Ethernet(tx+, tx-, rx+, rx-) and active line to any pin number of OBD2 except for ground pins and power pin. Fcar FVCI Passthru specification. Jan 07, 2018.ODIS Service Software update has been stabilized. VW ODIS Diagnostic Support Vehicle models list: Audi,Volkswagen,VW Nutzfahrzeuge,Seat,Skoda,Bentley,Lamborghini Detail vehicle please read the article: VW ODIS Diagnostic Support Vehicle models list VW ODIS Diagnostic Software Hardware: VAS 5054A.

How To Specify Vci Odis In Word
How To Specify Vci Odis In Computer
How To Specify Vci Odis In Windows 10

Original Fcar FVCI Passthru J2534 VCI Diagnosis, Reflash and Programming Tool works same function as Autel MaxiSys Pro MS908P. It supports J2534 protocol, and it will support other protocol for free later. In addition, the FVCI J2534 VCI supports multiply communication manner of DOIP protocol, and it can set up Ethernet(tx_+, tx_-, rx_+, rx_-) and active line to any pin number of OBD2 except for ground pins and power pin.

Fcar FVCI Passthru specification:

Hardware function
J2534	ISO15765
ISO14230
ISO9141
ISO14230
J1850
SCI
Single wire CAN
DOIP	Ethernet port convert to OBD2
Local area network of FVCI convert to OBD2
Program voltage port	5v-20v
Ethernet port	1. Ethernet port to ODB2 interface for DOIP
2. Ethernet port to local area network of FVCI
Analog input	15 pins analog input
Vehicle port	26 pins port communicate to vehicle
Update pin	Use for update firmware of FVCI
DC	12v power supply

Diagnose function

TOYOTA Techstream
HONDA HDS
Volkswagen ODIS
VOVOL VIDA
GM GDS
BMW ISTA
JARGUR LANDROVER JLR SDD

Acura, Honda
Audi
BMW
Chrysler, Dodge, Jeep, Eagle, Plymouth
Ford, Lincoln, Mercury
GM
Hyundai
Infiniti
Isuzu
Jaguar
Kia
Land Rover
Lexus
Mazda
Mercedes-Benz
Mini
Mitsubishi
Nissan
Porsche
Subaru
Suzuki
Toyota, Scion
Volkswagen
Volvo

How to install/set up Fcar FVCI J2534 software?

OEM official website : http://www.fcar.com

1. Software setup

The FVCI tool package is in the CD, or it can download from http://www.fcar.com.

2) Click “Next” button.

3) Go on click “Next” button

4)Click “finish” button. The software setup done.

2. Install .net framework4.0

1) FVCI connect to power, then the device working.

3) Click “Start”

4) Click “control panel”.

5) Change the view to small icon in the top right corner.

6) Find “Device manager”.

7) And you will find “FVCI” label. (The USB must be connected to the computer.)

8) Right click ”FVCI”, and click “Update Driver Software”.

9)Click “Browse my computer for driver ”.

How To Specify Vci Odis In Word

10）Click “Browse”, and input the driver path of USB driver package.

12) If there is a windows security popup, Click “Install this driver software anyway”.

How To Specify Vci Odis In Computer

13)　If following information displays, it means install successful.

How To Specify Vci Odis In Windows 10

14) Check the “device manager”, if you see below figure, it means FVCI has been connected to the computer.

15) Start running software.

How to Update Fcar FVCI J2534 Passthru Software & Firmware?

1. Click “FVCI” icon on the desktop. Note: The computer must be connected to internet.
2. Click “Read Version” can read FVCI software and hardware version.
3. Click “Firmware Update” can update the hardware.
4. Click “Software Update” can update the software.
5. Click”DOIP”, then click “Enter DOIP mode”, the FVCI will enter the situation of Ethernet convert to OBD2 of DOIP.
6. Click ”Firmware Refresh” when you operate“firmware update” error.

Update Tips
1) Please enable internet connection before upgrade
2) The firmware version and software version must be the newest version mean while. Other wise the device will appear some error.
3) If you use “Firmware update” failed, you can use “Firmware refresh”.
